Docker Setup For Taproot Assets

Taproot Assets now supports transfers over the Lightning Network.

This is still experimental, and you're advised to only attempt it on Testnet.

You should start by reading the documentation for Taproot Assets.

PRELUDE TO DIRECTIONS, SET TO SOFT MUSIC​

Some people might say -- why are you doing this in Docker? It's too complicated!

They might be right! But here is my reasoning.

To follow the rest of these directions, you must already have Docker and Docker Compose installed.

Assuming you are working on an Ubuntu or other debian distribution, you can follow these directions to install Docker and Docker Compose.

THE ACTUAL DIRECTIONS​

  1. We assume you are starting with a parent folder: workspace

1.25) We assume you're working on an Ubuntu machine or other Linux distro, or maybe a Mac if you really have to. Don't even think of trying this on Windows (unless you are very crafty with WSL and have experience running LND under WSL).

1.5) We assume you are already have a bitcoind testnet node running on your machine. One problem with Testnet is that it's nearly impossible now to get Testnet coins. Contact us if you're working on this an need us to send you some Testnet coins. Unfortunately, Taproot Assets is not compatible with "signets" like MutinyNet.

  1. Clone https://github.com/lightninglabs/lightning-terminal into workspace

2.5) Now you should have the folder: workspace/lightning-terminal

  1. cd into the lightning-terminal folder (which you just cloned)... ... and check out the appropriate tag... ... right now it is v0.13.991-experimental ... but by the time you are reading this, it might be something else...

  1. Make a new folder: workspace/terminal

  2. Make all these subfolders in workspace/terminal

   workspace/terminal/.lit
   workspace/terminal/.lnd
   workspace/terminal/.tapd
   workspace/terminal/go-bin
   workspace/terminal/src
   workspace/terminal/installers

  1. Copy the Dockerfile and docker-compose.yml and lit-testnet.conf from this page into the workspace/terminal folder

  2. Go into workspace/terminal and run this command to start the docker container, and run bash in that container, so you'll be on the command line in the running container. docker compose -f docker-compose.yml run render-mainnet bash

  3. You should now be on the command line in the docker container

  4. Hopefully you should be at the path /home/user/lightning-terminal in the container

  5. Now you need to compile lightning terminal

  6. Run these commands to compile the Go code into binaries...

    make install
    make go-install-cli

(you should see lots of console output... wait for a few minutes while the binaries are built)

  1. Now look in your workspace/terminal/go-bin folder .. you should see a bunch of compiled binaries.. ... note that there are separate binaries for lnd, litd, tapd, etc....

  1. Type exit to leave the docker container

  2. Launch the docker compose with: docker compose -f docker-compose.yml up

  3. Litd should run automatically when you start the docker container like this. (You can see the command: line in the docker compose file, that is what launches litd).

  4. In a new terminal window, "exec" into the running container with this command: docker compose -f docker-compose.yml exec litd-testnet bash

16.5) You should on the commmand line in the container again now.

  1. Now comes the confusing part ;). You need to use three different binaries, with different flags, to do different things. You should experiment with these commands...

lncli commands​

lncli --network testnet --rpcserver localhost:10011 --help

litcli commands​

litcli --network testnet --tlscertpath /home/user/.lit/tls.cert --rpcserver localhost:8443 --macaroonpath /home/user/.lit/testnet/lit.macaroon --help

litcli commands if you need to do stuff with assets (this is confusing)​

litcli --network testnet --tlscertpath /home/user/.lit/tls.cert --rpcserver localhost:8443 --macaroonpath /home/user/.lnd/data/chain/bitcoin/testnet/admin.macaroon --help

tapcli commands​

tapcli --network testnet --tlscertpath /home/user/.lnd/tls.cert --rpcserver localhost:10011 --macaroonpath /home/user/.tapd/data/testnet/admin.macaroon --help

  1. The first command you will need to run is: lncli --network testnet --rpcserver localhost:10011 create ... this "create" command will create your LND wallet. Make sure to write down the seed!

  2. LND, TAPD, and LITD should all now be running, and you should be able to look in the corresponding data folders...

    workspace/terminal/.lit
    workspace/terminal/.lnd
    workspace/terminal/.tapd

.... and you should see that TLS certificates and other necessary files have been created.

docker-compose.yml​

services:
  litd-testnet:
    build:
        context: .
        dockerfile: Dockerfile
    container_name: lit-testnet
    volumes:
      - type: bind
        source: ../../lightning-terminal
        target: /home/user/lightning-terminal
      - type: bind
        source: .lit
        target: /home/user/.lit/
      - type: bind
        source: .tapd
        target: /home/user/.tapd/
      - type: bind
        source: .lnd
        target: /home/user/.lnd/
      - type: bind
        source: ./lit-testnet.conf
        target: /home/user/.lit/lit.conf
      - type: bind
        source: ./go-bin
        target: /home/user/lightning-terminal/bin
      - type: bind
        source: ./src
        target: /src
      - type: bind
        source: ./installers
        target: /installers
    command: "litd"
    environment:
      - GOBIN=/home/user/lightning-terminal/bin
      - PATH=/usr/local/go/bin:/home/user/lightning-terminal/bin:$PATH
    network_mode: host

Dockerfile​

FROM ubuntu:22.04

RUN apt-get update && apt-get install -y \
    git \
    make \
    gcc \
    bash \
    jq \
    ca-certificates \
    gnupg \
    curl \
    sudo \
    wget \
    python3 \
    python3-pip \
    unzip

COPY ./installers /installers
RUN ls
RUN wget --no-clobber https://go.dev/dl/go1.22.5.linux-amd64.tar.gz -P /installers

WORKDIR /installers

RUN rm -rf /usr/local/go && tar -C /usr/local -xzf /installers/go1.22.5.linux-amd64.tar.gz \
    && rm -rf /installers

RUN apt-get update
RUN apt-get install -y ca-certificates curl gnupg
RUN mkdir -p /etc/apt/keyrings
RUN curl -fsSL https://deb.nodesource.com/gpgkey/nodesource-repo.gpg.key | gpg --dearmor -o /etc/apt/keyrings/nodesource.gpg
RUN echo "deb [signed-by=/etc/apt/keyrings/nodesource.gpg] https://deb.nodesource.com/node_18.x nodistro main" | tee /etc/apt/sources.list.d/nodesource.list
RUN apt-get update
RUN apt-get install nodejs -y
RUN npm install --global yarn

ENV PATH=$PATH:/usr/local/go/bin:/home/user/go/bin

RUN useradd -u 1000 user \
    && echo "user:password" | chpasswd \
    && adduser user sudo
# Grant permissions to the user
RUN mkdir -p /home/user/go/pkg \
    && chown -R user:user /home/user/go \
    && chmod -R 755 /home/user/go

RUN mkdir -p /home/user/.cache/go-build \
    && chown -R user:user /home/user/.cache

RUN chown -R user:user /home/user
USER user

WORKDIR /home/user/lightning-terminal

lit-testnet.conf​

This is the configuration file for Litd. You can see that it is loaded in the docker-compose.yml file, above.

# LND mode integrated
lnd-mode=integrated
network=testnet

# UI password
uipassword=your_uipassword_here

# Bitcoin configuration for LND
lnd.alias=[PUT SOMETHING HERE]
lnd.bitcoin.active=1
lnd.bitcoin.node=bitcoind
lnd.bitcoind.rpchost=127.0.0.1:18332
lnd.bitcoind.rpcuser=david-foster-wallace
lnd.bitcoind.rpcpass=the-pale-king
lnd.bitcoind.zmqpubrawblock=tcp://127.0.0.1:29000
lnd.bitcoind.zmqpubrawtx=tcp://127.0.0.1:29001
lnd.bitcoin.testnet=true

# LND listen and debug settings
lnd.rpclisten=0.0.0.0:10011
lnd.accept-keysend=true
lnd.debuglevel=trace,GRPC=error,PEER=info,DISC=info,CMGR=info,BTCN=info
## lnd.externalip=[ADD THIS FOR EXTERNAL IP]
## lnd.listen=0.0.0.0:9736  [ADD THIS FOR EXTERNAL IP]
lnd.maxpendingchannels=10
lnd.norest=true

# LND protocol options
lnd.protocol.option-scid-alias=true
lnd.protocol.zero-conf=true
lnd.protocol.simple-taproot-chans=true
lnd.protocol.simple-taproot-overlay-chans=true
lnd.protocol.custom-message=17

## experimental taproot assets stuff
taproot-assets.experimental.rfq.priceoracleaddress=use_mock_price_oracle_service_promise_to_not_use_on_mainnet
taproot-assets.experimental.rfq.mockoracleassetsperbtc=698050000

What does taproot-assets.experimental.rfq.mockoracleassetsperbtc do?​

This setting is related in a potentially confusing way to to concept of decimal_display, which is a parameter you need to provide when minting an asset. It's critical you understand what decimal_display does. Looking at this pull request can help: https://github.com/lightninglabs/taproot-assets/pull/1059

How Do I Know If I Have All The Binaries Installed?​

Run the getinfo commands with all three binaries....

Note -- instead of the full command, like

tapcli --network testnet --tlscertpath /home/user/.lnd/tls.cert --rpcserver localhost:10011 --macaroonpath /home/user/.tapd/data/testnet/admin.macaroon

... below you see that I am using shell scripts that run that same command and append to it any argument provided to the script... in the examples below, "getinfo" is appended.

user@aw60:/src$ ./litcli-testnet.sh getinfo
{
"version": "0.13.991-experimental commit=v0.13.991-experimental-dirty"
}
user@aw60:/src$ ./tapcli-testnet.sh getinfo
{
"version": "0.4.1-alpha commit=v0.4.1",
"lnd_version": "0.18.0-beta",
"network": "testnet3",
"lnd_identity_pubkey": "020c3b59b1854d31b94c0dd9df1019d251b4cd5565129f7ad16e3ec8c4671afd8c",
"node_alias": "Megalith Assets Testnet",
"block_height": 2871478,
"block_hash": "000000000000000c2868d2567b55d885ea1bd803d385a3d949d577a66c45bca0",
"sync_to_chain": true
}
user@aw60:/src$ ./lncli-testnet.sh getinfo
{
"version": "0.18.0-beta commit=lightning-terminal-v0.13.991-experimental-dirty",
"commit_hash": "3280923f3cb8e0ae10f5858b354e92ebdc37c51f",
"identity_pubkey": "020c3b59b1854d31b94c0dd9df1019d251b4cd5565129f7ad16e3ec8c4671afd8c",
"alias": "Megalith Assets Testnet",
"color": "#3399ff",
"num_pending_channels": 0,
"num_active_channels": 5,
"num_inactive_channels": 3,
"num_peers": 5,
"block_height": 2871478,
"block_hash": "000000000000000c2868d2567b55d885ea1bd803d385a3d949d577a66c45bca0",
"best_header_timestamp": "1722542222",
"synced_to_chain": true,
"synced_to_graph": true,
"testnet": true,
"chains": [
{
"chain": "bitcoin",
"network": "testnet"
}
],
"uris": [
"020c3b59b1854d31b94c0dd9df1019d251b4cd5565129f7ad16e3ec8c4671afd8c@164.90.144.205:9736"
],
